SPECIFICATIONS
8 ch
Channels:
DSM2/DSMX
Modulation:
2.4 GHz
Band:
30
Model Memory:
1500 Nimh
Transmitter Battery Included:
FEATURES
High-speed 11ms frame rate with 2048 resolution
30-model internal memory
Large 128 x 64 backlit screen
30 model memory
Includes 2000mAh Ni-MH battery pack
Includes SD card for Spektrum Data Interface
Includes global 12V charger with adapters for international use
Includes Spektrum neckstrap
Exclusive Spektrum AirWareâ„¢ software
SimpleScrollâ„¢ programming interface for easy menu navigation
5-point graphic tail curve
5-point graphic throttle and pitch curve
Active gain and governor trim allows in-flight adjustment
Swash plate timing
Telemetry alerts (vibe and audible)
4 swash plate types
8 wing types and 5 tail types
Language select (English, Italian, French, Spanish or German)
User-assigned switch function
Programmable throttle cut
Refined ergonomics with no-slip comfort grips
Programmable timer with throttle timer startup
Quad bearing gimbals
Spektrum Data Interface for expanded model memory, model sharing, and firmware updates
3-position flap switch with flap delay and elevator compensation programming
4 user-selectable control modes (Mode 1, Mode 2, Mode 3 and Mode 4)
Important note: The DX8 has a multi chemistry battery charger built into the radio. The included wall adapter is a power supply, not a battery charger. This means that the DX8 CANNOT be charged through the charge jack with anything but the included power supply. Charging with any other charger will seriously damage the radio, which under no circumstances will be covered under warranty.
Combining Spektrum™ industry-leading 2.4GHz DSM® technology with real-time telemetry in this DX8 represents a breakthrough in 8-channel sport-level radio systems. The telemetry module is expandable based on the module needs; the module is capable of supporting Quality of Signal (Antenna Fades, Frame losses, holds), Receiver Pack Voltage, RPM, Temperature and Flight Pack Voltage. Enthusiasts can add the safety of real-time telemetry and monitor vital aircraft stats right from their transmitter without any additional equipment. Keep your engine operating in the optimum temperature range, keep an eye on your battery voltage, and check out just how fast your aircraft is running all right from the large LCD readout of the DX8.
