Motor Features
• The sturdy gold-plated PCB circuit board makes it easy to solder Electronic Speed Control (ESC) cables, resulting in a more flawless wiring setup
• The standard sensor port 5PIN-1.27 terminal sensor wires connection.
• High slot full resistance internal resistance for high power output.
• Unique stator adopts 0.2mm silicon steel sheet, efficiency rate can reach 94%.
• Explosion-proof new magnetic rotor with 2Pole Super compliant linear high speed high temperatures 200°C .
• 1EI/AIW (H) US Standard MWS Brand Red High Temperature Wire Rod.
ESC Features
• Specially designed for RC Crawlers
• The power system of a rock crawler benefits from speed closed-loop control. The low-speed torque is notably robust, surpassing both regular sensored brushless and even brushed power systems. With intelligent torque output and speed closed-loop control, it becomes easier to manage and ensures a consistent motor RPM regardless of the load.
• Built-in switch-mode BEC 5V/500mA for usage with high torque and high voltage servos.
• Multiple protection features: Low voltage cut-off protection for lithium or nickel battery / Over-heat protection / Throttle signal loss protection / Motor blocked protection/
• Excellent heat dissipation.
