    This is the Onyx 3S 7.4V 600mAh 25C LiPo Battery with Micro Connector.

FEATURES: Ultrasonically welded cell tabs and balancing wires
2-year limited warranty-Onyx brand batteries are warranted to be
free from defects in materials and workmanship for a period of two
years from the date of purchase. During the first twelve months,
ONYX will, at our discretion, repair or replace without service
charge any product deemed inoperable due to those causes.
After the first full year of warranty coverage ONYX will provide
extended warranty coverage for another 12 months covering only
defects in materials and workmanship. Extended coverage is limited
and does not cover problems caused by abuse, misuse, and improper
maintenance, failure to follow instructions, ordinary wear, or use
past the battery's maximum rated number of cycles.

INCLUDES: Onyx 3S 7.4V 600mAh 25C LiPo Battery with Micro Connector and JST-XH
Balancing Connector

REQUIRES: LiPo compatible charger
LiPo charging bag
If using one of the Duratrax chargers listed in the Accessory
Completion Guide, the Micro Charge Lead (GPMM3149) is required
Charge lead is also compatible with other chargers.

SPECS: Voltage Rating: 11.1V
Rated Capacity: 600mAh
Maximum Charge Rate: 2.4A/3C
Discharge Rate: 25C
Burst Rate: 50C, 30A
Dimensions: 2.0 x 1.2 x 0.83" (52 x 32 x 21mm)
Weight: 2.1oz (60g)
Discharge Lead Wire Size: 18AWG
Discharge Lead Length: 3" (76mm) not including connector
Discharge Connector: Micro
Balancing Connector: JST-XH
Watt Hours: 6.7

COMMENTS: ALWAYS use a LiPo-approved Charger and Cell Balancer
NEVER Charge over 4.20V per cell
NEVER Charge at currents greater than 3C
NEVER Trickle Charge
NEVER allow to Discharge below 2.5V per cell
NEVER disassemble or modify pack wiring in any way or puncture cells
NEVER place on combustible materials or leave unattended during
charging
ALWAYS Charge in a fireproof location
ALWAYS set charger's output volts to match battery volts
ALWAYS keep out of reach of children
All weights include wire leads and plugs
All weights +/- 1 g
All measurements +/- 1 mm
