Servo HS1005SGT Ultra Duty Torque Full Metal Case Digital
|
|
||||
 |
||||
|
||||
|
|
||||
 |
||||
|
||||
|
|
||||
 |
||||
|
||||
|
|
||||
|
|
||||
|
||||
|
|
||||
 |
||||
|
||||
|
|
||||
 |
||||
|
||||
 |
|
|
|
 |
StockStock availability for on-line ordering
StockStock availability for pick up
This live feed
information is to be used as a general guide to current inventory. There is no guarantee of
availability.
SPECIFICATIONS
15 Tooth
Output Spline:
64.0 mm
Length:
33.0 mm
Width:
73.0 mm
Height:
363 g
Weight:
11.1-14.8 v
Voltage Range:
1167 oz-in
Torque @ 11.1V:
0.26 sec/60°
Speed @ 11.1V:
1528 oz-in
Torque @ 14.0V:
0.19 sec/60°
Speed @ 14.0V:
FEATURES
Features:
- High Response Digital MOSFET Amplifier
- Hardened Steel Gears with MPD First Gear
- Long Life Potentiometer
The ultra heavy duty, giant scale HS-1005SGT delivers digital precision and high voltage punch to your most demanding projects. Designed with an all-aluminum, EMI-shielded case, solid steel gears and non-programmable digital circuitry, this powerhouse servo can tackle the most extreme 1/5th scale vehicle stunts and giant scale aerobatic maneuvers in addition to the industrial applications that inspired its original design. Capable of operating on 14.8 volts, the HS-1005SGT is the ultimate in power and durability.
HIT34105S
