SPECIFICATIONS
400 x 400 x 400 mm
Print size:
<90 °C
Bed Temp:
<260 °C
Nozzle Temp:
4.3in Colour Touchscreen
Display:
725 x 640 x 691 mm
Dimensions:
PLA/TPU/PETG/Wood
Supported filaments:
FEATURES
The Golden Triangle
Holding up the towering Z-axis are the supporting rods that Creality has previously dubbed “The Golden Triangle”. These metal supports help to reduce vibrations as the bed is moving back and forth.
The appearance of these is a welcome and means that you will be able to print taller without having to worry about excessive Z-wobble as you reach the upper limits of the build volume.
Automatic Leveling System
The CR-6 Max 3d printer features the same innovative leveling system as the CR-6 SE, using a force-based sensor. The Max will simply touch the nozzle to the bed at specific points, and a strain sensor on the hot end will detect the exact point at which the nozzle touches the glass.
This system is nice for a number of reasons. For one, there is no extra sensor probe, meaning you don’t need to calibrate any offsets other than the initial Z height to get the right “squish” in your first layer. Also, the automatic leveling system does away with the knobs on the underside of the bed, which will be a relief for anyone who has experience trying to level such large-format machines.
Further Features
Additional features the Creality CR-6 Max 3d printer will include:
Modular Nozzle: Creality designed the nozzle with modularity in mind. Users can disable the nozzle and change the heat block, heat sink, Teflon tube, or the nozzle tip with the included spares.
Extruder: The redesigned extruder allows for easier feeding of filament.
Filament Sensor: The CR-6 Max 3d printer is equipped with a photoelectric filament sensor detecting any possible filament breakage or runout.
Resume Print Function: Outages or disconnections should be no problem for the CR-6 Max because it can fully recover and resume the print when it’s back up.
32-Bit Motherboard: The CR-6 SE reached one of its stretch goals on Kickstarter, meaning that both the SE and the Max will be delivered with a 32-bit motherboard for enhanced performance.
