Matrix 1S Brushed Flight Controller G4 4n1 V1.1

Bullet Points

• Dual DNA: 3IN1 (FC, ESC, and ELRS 2.4G RX) for DJI O4 digital dominance (omits analog OSD), 4IN1 for analog mastery with OSD.
• STM32G473 MCU: 55% faster processing than F411 for responsive tuning.
• Stable Video Transmission: Features a newly developed BEC to ensure consistent power delivery for seamless HD performance.
• Enhanced Overcurrent Capacity: Supports 12A continuous current and 18A peak ESC, providing robust performance for demanding flights.
• Reliable Precision: Includes an independent 3.3V LDO design to deliver stable, interference-free power directly to the IMU for accurate control.
• Whoop-ready Installation: The 3IN1 is equipped with motor plugs and a SH1.0-6Pin HD digital port for a hassle-free installation and maintenance experience, while the 4IN1 has external VTX soldering pads for protocol flexibility.

Specifications

• MCU: STM32G473CEU6 (168MHz)
• Gyro: ICM42688P
• Blackbox Memory: 16MB
• Sensor: Voltage & current
• BEC: 5V/3A
• UART (3IN1 Version): UART 1 (RX Only/SBUS), UART 2 (Free), UART 3 (For RX), UART 4 (Free/HD MSP)
• UART (4IN1 Version): UART 1 (For VTX), UART 2 (Free), UART 3 (For RX), UART 4 (NONE)
• ESC: 12A continuous
• RX: Serial ELRS 2.4GHz (V3.4.3)
• FC Firmware: Betaflight_4.5.1_BETAFPVG473 (3IN1 version), Betaflight_4.5.2_BETAFPVG473_V2 (4IN1 version)
• USB Port: SH1.0-4Pin
• OSD: AT7456E (4IN1 version only)
• HD Digital VTX Port: SH1.0-6Pin (3IN1 version only)
• Motor Plug: JST1.25-3Pin
• Battery Connector: BT2.0
• Mounting Size: 25.5mm x 25.5mm
• Weight (3IN1 Version): 3.8±0.1g (battery connector excluded), 4.2±0.1g (battery connector included)
• Weight (4IN1 Version): 3.6±0.1g (battery connector excluded), 4.6±0.1g (battery connector included)
