TGHRX-LCD5802

7" LCD Screen w/5.8GHz Diversity Rx/Int LiPo/No Chg

Product Info | Optional Items
RESOURCES

Optional Items (2)
TEAM GREAT HOBBIES

TGHRX-LCD5802
7" LCD Screen w/5.8GHz Diversity Rx/Int LiPo/No Chg
By TEAM GREAT HOBBIES
$134.99 CAD    159.99
Save $25.00 (16%)

Order Quantity:
Click to Enlarge
click to enlarge

More like this... Video Equipment Accessories, Display
But only from... TEAM GREAT HOBBIES


 Inventory Status Legend
Stock availability for on-line ordering
0
$134.99
Warehouse ?
Stock availability for pick up
0
$134.99
Warehouse ?
0
$134.99
Store - Charlottetown ?
0
$134.99
Store - Edmonton ?
0
$134.99
Store - Mississauga ?
0
$134.99
Store - Ottawa ?
This live feed information is to be used as a general guide to current inventory. There is no guarantee of availablility.
FEATURES
  • 7" TFT LCD screen 800x480 LED back lit
  • Brightness: 450cd/m2
  • Viewing Angle: 140deg Horizontal, 120deg Vertical
  • Integrated Dual Diversity 5.8GHz Video Receiver, automatically switches to best reception
  • Integrated 7.4V 2450mAh LiPo Battery provides plenty (2hrs+) of use
  • Dual buffered AV outputs for recorder and video goggles
  • Receives all 4 Bands, 32 Channels for compatibility with most systems
  • Automatic signal search function
  • Work Status On-Screen Display: RSSI, Battery and Channel Indication
  • Input Voltage: DC 7-16V, automatically charges integrated LiPo Battery
  • Includes AC adapter for charging and benchtop operation
  • Antenna type: SMA connector

This all in one solution offers the best value for an FPV ground station for those not using video glasses or to provide a second screen for your buddies to join in the fun!  This compact solution features dual diversity video receivers which automatically select the strongest cleanest signal for display.  Super easy to use, the automatic search function lets you lock onto your video signal with the push of a button.  Purchase the optional transmitter mount and attach the screen directly to your RC transmitter for hands free operation.  The unit can also be tripod mounted or simply hand held by your buddy, the complete absence of external wiring makes it a breeze to operate and completely portable.  Comes with two linear antennas, add a circular polarized antenna for increased performance.
