   This is the 1/10 scale electric powered, radio controlled, 2WD, on-road
Tamiya F103GT Racing Car Kit with the Nissan GT-R LM Nismo Body.

FEATURES: Chassis: F103GT, FRP double deck frame (lower 2.5mm thick, upper
1.5mm thick)
Drive: Solid axle rear wheel drive
Gearbox: Single speed, height adjustable for wide range of settings
Motor: 540 size brushed
Ball Bearings: Full set, shielded
Differential: Ball type pressure plate
Tires: Slick rubber, width .94" (24mm), outer diameter 2.4" (61mm),
1.9" (48mm) inner diameter, foam inserts
Wheels: Black, 0.94" (24mm) wide, 1.9" (48mm) diameter
Front Suspension: Independent link type arm and coil springs
Rear Suspension: Rigid, uses FRP T-bar, friction plate and coil
spring, adjustable shock angle
Motor Mount: Height adjustable for different ground clearance
settings
Body: Clear untrimmed molded polycarbonate
Caster: Adjustable, caster/toe-in refers to the angle of the front
suspension when viewed from the side of the car in relation to the
chassis, 3 caster angle built-in
Camber: Non adjustable, camber refers to the angle of the tops of the
tires from vertical when when viewed from front or behind
Steering: Direct servo mechanism

INCLUDES: Tamiya F103GT On-Road Racing Car Kit, 540 Motor, Clear Body, Decal
Sheet, Tires, Foam Inserts, Wheels, 14T aluminum pinion gear, 70T
Plastic Spur Gear, Instruction Manual

REQUIRES: Radio: Two channel with steering servo
Radio Batteries: Eight AA size
Speed Control: Electronic
Battery: 6-cell flat pack with standard connector, 7-cell will not
fit.
Charger: AC/DC timed or peak for 6-cell battery
Paint: Spray or brush-on polycarbonate safe
Misc. Items: Building and track equipment

SPECS: VEHICLE-
Length: 16.8" (426mm)
Width: 7.4" (189mm)
Height: 4.1" (105mm)
BODY-
Length: 16.81" (427mm)
Width: 7.4" (189mm)
Height: 3.2" (81mm)

COMMENTS: For Replacement Ball Bearings use:
Qty. Size Location Qty Bearing Set
2 10x6mm Rear Axle Shaft 1 DTXC1561
4 5x8mm Front Wheels 2 DTXC1523
2 8x12mm Ball Diff 1 DTXC1581
1 5x11mm Ball Diff 1 DTXC1547
