TAM58575

1/12 Lunch Box Blue Style CW01

Product Info | Replacement Parts | Optional Items
RESOURCES

Replacement Parts (6)
Optional Items (9)
TAMIYA

TAM58575
1/12 Lunch Box Blue Style CW01
By TAMIYA
Discontinued
Click to Enlarge
click to enlarge

More like this... R/C Electric Monster Truck Kits
But only from... TAMIYA


 Inventory Status Legend
Stock availability for on-line ordering
0
$176.79
Warehouse ?
Stock availability for pick up
0
$176.79
Warehouse ?
0
$176.79
Store - Charlottetown ?
0
$176.79
Store - Edmonton ?
0
$176.79
Store - Mississauga ?
0
$176.79
Store - Ottawa ?
This live feed information is to be used as a general guide to current inventory. There is no guarantee of availablility.
PRODUCT RESOURCES
VENDOR TECHNOTES
          This is the electric powered, radio controlled, 1/12 scale,
Tamiya Lunch Box Kit with Blue Body.

FEATURES: Chassis: ABS plastic box type with metal wheelie bar
Drive: Rear wheel
Motor: 540 size
Pinion Gear: 10T metal
Electronic Speed Control: Tamiya TEU-105BK with reverse
Differential: Planetary gear
Gearbox: Sealed
Shocks: Friction type
Suspension: Coil spring damped front and rear with front independent
swing axle, rigid rear axle
Body: Shock resistant styrene, molded in blue
Steering: Rod with ball adjuster and servo saver
Tires: 4.5" (115mm) diameter, 2.5" (65mm) wide all terrain
Wheels: Black plastic 2.2" (55mm) diameter, 2.5" (65mm) wide
Camber and Caster: Fixed, non-adjustable

INCLUDES: 1/12 scale Tamiya Lunch Box Kit with Blue Body and Wheels, ESC
540 Motor, Servo Saver, Decals and Instruction Manual

REQUIRES: Radio: 2-channel with steering servo
Battery: 6-cell, 7.2V NiMH stick pack with standard connector
Battery Charger: To match selected battery
Transmitter Batteries: Four or eight depending on transmitter
Tools and track equipment

SPECS: Vehicle;
Length: 15.1" (385mm)
Width: 11.4" (290mm)
Height: 8.8" (225mm)
Weight: 3.4lbs (1560g), approximate
Body;
Length: 11.8" (300mm)
Width: 5.8" (148mm)
Height: 4.3" (110mm)

COMMENTS: To upgrade to Ball Bearings use:
Qty. Size Location Qty. Bearing Set
2 5x11mm Left Rear Shaft 1 DTXC1547
2 5x11mm Right Rear Shaft 1 DTXC1547
4 5x11mm Front Wheels 2 DTXC1547

jxs 08/21/13
ir/jxs
4950344585755 4950344585755
TAMC8575
