TAM57850

1/10 Pumpkin RTR Black Edition

Product Info | Replacement Parts | Optional Items
TAMIYA

TAM57850
1/10 Pumpkin RTR Black Edition
By TAMIYA
Discontinued
Click to Enlarge
click to enlarge

More like this... ARR R/C Electric Monster Trucks
But only from... TAMIYA
All items from... TAMIYA


 Inventory Status Legend
StockStock availability for on-line ordering
0
$263.49
Warehouse ?
StockStock availability for pick up
0
$263.49
Warehouse ?
0
$263.49
Store - Charlottetown ?
0
$263.49
Store - Edmonton ?
0
$263.49
Store - Mississauga ?
0
$263.49
Store - Ottawa ?
This live feed information is to be used as a general guide to current inventory. There is no guarantee of availablility.
Best selling related parts, options and upgrades...
Small Metric 4-Way Wrench
$4.99

3mm Grub Screw 44002
$5.99

Body Pin Set
$4.99

1150 Sealed Ball Bearing Set (2)
$19.99
Shaft Bag 58347
$17.99

Spring Mount 58035 2pc
$5.99

Tire 58063/70 (4)
$31.99

Hex Screw Mount 58266
$7.99
click image to enlarge
ADDITIONAL PHOTOS

PRODUCT RESOURCES
VENDOR TECHNOTES
This is the 1/12 scale, electric powered, 2.4GHz radio controlled, ready to run
Tamiya Black Edition Midnight Pumpkin On-Road Truck.

FEATURES: Chassis: ABS plastic box type with metal wheelie bar
Drive: Rear wheel
Motor: Brushed 540 size
Radio System: Tamiya Finespec 2.4GHz pistol grip with steering and
throttle trim and reverse and steering servo
Electronic Speed Control: Tamiya TEU-105BK with reverse
Body: 1950's pickup style PS injection molded, black in color with
pre-applied decals
Shocks: Four plastic bodied friction (not oil filled) type
Gearbox: Sealed
Transmission: Single-speed
Differential: Planetary
Tires: 4.5" (115mm) diameter, 2.7" (69mm) wide monster truck type
Wheels: 2" (51mm) diameter, 2.5" (64mm) wide yellow plastic
Bumpers: Front plastic
Camber Tie Rods: Fixed, non-adjustable
Caster: Adjustable, caster/toe-in refers to the angle of the front
suspension when viewed from the side of the car in relation to the
chassis

INCLUDES: Tamiya Black Edition Midnight Pumpkin with shocks, 540 motor,
Electronic Speed Control, radio, body, tires, decals, wheelie bar
32 pitch 17 tooth and 50 tooth spur gear, radio, instructions

REQUIRES: AA Batteries: Eight AA size for trasnsmitter
Battery: 6-cell 7.2V stick pack
Charger: AC/DC Timed or Peak for 6-cell battery
Misc. Items: Building and track equipment

SPECS: VEHICLE-
Length: 15.25" (387mm)
Width: 11.1" (282mm)
Height: 10.7" (271mm)
Weight: 3.8 lbs (1725g) without battery
Wheelbase: 8.25" (209mm)
Front Tread: 8.8" (223mm)
Rear Tread: 8.5" (216mm) measured at wheel centers
Front Track: 10.3" (262mm)
Rear Track: 10" (255mm) measured at outer edges of wheels
Ground Clearance: 2.25" (57mm)
Gear Ratio: 14.7:1
Tires: 4.5" x 2.7" (115mm x 69mm)
BODY-
Length: 14" (359mm)
Width: 7.8" (198mm)
Height: 4.9" (109mm)

COMMENTS: For Replacement Ball Bearings use:
Qty. Size Location Qty. Bearing Set
4 5x11mm Rear Wheel Shafts 2 DTXC1547
4 5x11mm Front Wheels 2 DTXC1547
