The first FPV camera integrated gyro displays accurately your impressive perspective.
Pilots will find their best flight angle with this by continuously fine-tuning their camera elevation.
The camera can independently display the real-time angle, it also can connect with the betaflight
flight control serial port to calculate and display the flight control angle.*
*For betaflight versions before 4.3, turn on the MSP switch of the connected serial port first.
With betaflight 4.3, select runcam device, camera remote control + flight control gyroscope combo directly.
Model RunCam Racer 5
Image Sensor Super WDR CMOS Sensor
Horizontal Resolution 1000TVL
Lens
1.8mm FOV160° 2.1mm FOV 145°
Screen Format 4:3 / Widescreen Switchable
Signal System NTSC / PAL Switchable
Mirror/Flip Available
Integrated OSD Yes
Built-in gyro Yes
One Touch Scene Setting Personal / Lightrax
S/N Ratio >50dB
Electronic Shutter Speed Auto
Min. Illumination 0.01Lux@1.2F
WDR Super WDR
Day/Night Color
Menu Control Cable Control / Remote Control
Power DC 5-36V
Current 110mA@5V / 40mA@12V
Housing Material ABS
Net Weight 6.1g
Dimensions L19mm*W19mm*H21mm
