FEATURES
Size: 1.15 x 0.95 x 0.66" (29.0 x 24.3 x 16.8mm)
Input Voltage: 2S LiPo/LiFe cells or 4-7 NiMH cells (1.2V/cell)
Motor Limit: 540 (10.5T and higher) sensored brushless motor, all 380 sensored brushless motors
On-Resistance: 0.00057 ohms @25° trans. temp BEC: 6.0V DC/2.0 amps
Status LEDs: Five
Voltage Cut-Offs: 6.25V (LiPo), 4.75V (LiFe)
Power Wires: 14G Super-Flex Copper-Strand Silicone Wire Motor
Watts: 130
Color-Coded Stator: Yellow
Maximum RPM: 50,000
Sensor Harness Length: 9" (230mm)
Motor Size: 2.07 x 1.41" (52.6 x 35.8mm) (540 size)
