FEATURES
The Moxon antenna is designed and manufactured by BETAFPV for the 2.4G/915MHz/868MHz TX module. The Moxon antenna is a directional antenna with a high gain of 5.5dbi to the front.
New Features
BETAFPV Moxon Antenna has been very popular with pilots since its release. By taking the features of Moxon and adding some new ones, the coaxial cable of Moxon V2 is soldered to the antenna, decreasing the signal transmission loss for better performance. Besides, the soldered joint is protected by an injection molding cover, making it a whole unit and very easy to install.
Moxon Antenna V2
Coaxial cable length: 65mm(2.4G)/90mm(915M)
Connector: SMA Male
Gain: 5.4dBi(2.4G)/5.9dBi(915M)
VSWR: <2.0(2.4G)/<2.0(915M)
Polarization type: Linear polarization
Suggested for: Any 2.4G/915MHz TX module or radios
Suggested for: BETAFPV Nano TX Module/BETAFPV Micro TX Module, Any 2.4G/868MHz/915MHz TX module or radios
