SPECIFICATIONS
40 x 20 x 38 mm
Dimensions:
402.73 oz-in
Torque @ 6.0V:
486.05 oz-in
Torque @ 7.4V:
0.15 sec/60°
Speed @ 6.0V:
0.13 sec/60°
Speed @7.4V:
68 g
Weight:
FEATURES
Coreless Motor.
Titanium gears.
G2 programmable digital circuit.
Can be run off of a 2s li-po pack without the use of a voltage regulator.
Gold plated contacts.
Water and dust resistant- Not water proof.
Ideal for larger helicopters and cars needing high speed and plenty of torque.
A note on coreless motors
A conventional servo motor has a steel core armature wrapped with wire that spins inside the magnets. In a coreless design, the armature uses a wire mesh that forms a cup that spins around the outside of the magnet. This arrangement is much lighter resulting in smoother operation and faster response time.
