GPMQ3794

4-40 Thread Steel Clevis (2)

Product Info | Substitutions
RESOURCES

Substitutions (1)
GREAT PLANES

GPMQ3794
4-40 Thread Steel Clevis (2)
By GREAT PLANES
$2.89 CAD
Order Quantity:
No Picture Available

More like this... Linkage, Clevis
But only from... GREAT PLANES


 Inventory Status Legend
Stock availability for on-line ordering
0
$2.89
Warehouse ?
Stock availability for pick up
0
$2.89
Warehouse ?
0
$2.89
Store - Charlottetown ?
0
$2.89
Store - Edmonton ?
0
$2.89
Store - Mississauga ?
0
$2.89
Store - Ottawa ?
This live feed information is to be used as a general guide to current inventory. There is no guarantee of availablility.
PRODUCT RESOURCES
VENDOR TECHNOTES
           This is a package of two 4-40 Threaded Steel Clevises.

FEATURES: Made of steel
Has a barb on the clevis to hold the retainer in place
Has a stepped clevis pin to reduce friction

INCLUDES: Two threaded steel clevises
Two retainers (sections of standard fuel tubing)

SPECS: Fits 4-40 threaded rods
Length: 1.2" (30.4mm) end to end
.75" (19.1mm) of clevis opening
Width: .18" (4.7mm) @ widest point on the pin end
Height: .17" (4.3mm) @ highest point on the pin end
.12" (3.1mm) of clevis opening
Diameter: .06" (1.5mm) of pin

COMMENTS: These steel clevises are used to connect a 4-40 pushrod to a control
such as a control horn or throttle lever.
btm 06/14/94
ir/jl
updated 070204 tjt
735557637941 0735557637941
GPMQ3794
